KROM SCHRODER VAS 115R/NW / solenoid valve

KROM SCHRODER VAS 115R/NW / solenoid valve

Application

Solenoid valves for gas VAS and double solenoid valves VCS
for safeguarding and controlling the air and gas supply to gas
burners and gas appliances. For use in gas control and safety
systems in all sectors of the iron, steel, glass and ceramics
industries, also in commercial heat generation, such as the
packaging, paper and foodstuffs industries.

Function

The gas solenoid valve VAS is closed when it is disconnected
from the power supply.
Opening: Connect the system to the electrical power supply
(alternating voltage will be rectified). The blue LED lights up. The
coil’s magnetic field pulls the armature with the attached valve
disc upwards. The gas solenoid valve VAS opens. The double
valve seat means that the forces from the inlet pressure are
divided almost equally between the two valve seats.
Closing: Disconnect the VAS from the electrical power supply.
The blue LED goes out. The armature is pressed into its initial
position by the closing spring. The gas solenoid valve closes
within 1 s.
The strainer in the inlet of the gas solenoid valve prevents
deposits of dirt particles on the valve seats. The pressure loss
through the strainer is very low.
